BOSCH Horn GENERAL
0.00(0)
EGP 540
System Type 5-way Coaxial
Sound Pressure Level (Sensitivity) 90 dB (+- 1.5dB)
Frequency Range 22 Hz to 25 kHz
Continuous Power Handling (RMS) 120 Watts
Maximum Peak Power Handling 700 Watts
Nominal Impedance 4 ohms
Diameter 6 x 9"
Cone Material Carbon and mica reinforced IMPP
Surround Material Elastic polymer
Magnet Material Ferrite
Magnet Weight 15.2 oz
Mounting Depth 3-3/8" (Deep basket)
Type Triple Polyethylene terephthalate (PET) dome tweeter
Diameter 9 mm (Super), 11 mm, and 18 mm
Crossover Frequency 3,600 Hz
