BOSCH Horn GENERAL
0.00(0)
EGP 540
Performance Standard series amplifiers are designed to be our best sounding amplifiers. They provide outstanding dynamics, holding the musical reproduction to the highest standard whether delivering impactful bass or the most detailed notes.
| Performance Standard Serie |
| Stereo or mono setup |
| 500W Maximum output power |
| Built-in Low-pass filter |
| Signal Sensing Turn-on |
| Speaker level input |
| Power MOS-FET switching power supply |
| Die cast aluminium heat sink |
| Load Capability | 2Ω Stable |
| Maximum power output | 500W |
| Rated power output (4Ω) | 70W x 2 (4Ω) |
| Rated power output | 60W x 2 (4Ω) |
| Bridged power output (4Ω) | 170W x 1 |
| CEA-2006 Compliant | Yes |
| Low-pass Filter | Yes |
| Switched Mode Power supply | Yes, MOS-FET |
| Signal Sensing Turn-on | Yes |
| Line in | 2 RCA's |
| Speaker level Input | Yes |
| Single Side Terminals | Yes |
| Die-Cast Aluminium Heat Sink | Yes |
| Rated power output (4Ω, 14,4V) | 70W x 2 (20Hz ~ 20000Hz, 1%THD) |
| Rated power output (2Ω, 14,4V) | 85W x 2 (1000Hz, 1%THD) |
| Rated power output (CEA-2006) | 70Watts RMS x 2 at 4 ohms and 1% THD |
| Low-pass Filter | 80Hz (-18dB/oct) |
| RCA Input Sensitivity | 0.2 ~ 5V |
| Speaker Level Input Sensitivity | 4 ~ 12V |
| Input Impedance | 10kΩ |
| Signal to Noise Ratio | 100dB |
| Signal to noise ratio (CEA-2006) | 80dBa (Reference: 1 Watt into 4 Ohms) |
| Frequency response (+0dB, -3dB) | 20Hz ~ 50Hz |
| Operating voltage | 14.4V (11V ～ 16V allowable) |
| Maximum current consumption | 15A |
| Dimensions (WxHxD) | 230 x 56 x 167(mm), |
| Weight | 1.4kg |
